Dr Al Porterfield has two large PSYLAB systems which are used for student projects.

Below, laboratory 1.

PSYLAB EEG8 and Bio2 pre- amplifiers mounted in a recessed panel in the subject room.

Laboratory 2, which includes blood pressure monitors connected directly to the PSYLAB computer.

Below, blood pressure monitors Finapres (left) and SD700A. The Finapres uses a finger cuff and produces a continuous BP readout. The SD700A uses an arm cuff which inflates under control of the PSYLAB computer.
